The 4 wires that were added to the C405 inline 16 pin male connector in the previous step must be routed from the rear of the vehicle along the LH frame rail and connected to the C327 female inline 12 pin connector of the 14405 frame harness using (4) DU2Z-14474-DA (Motorcraft part # WT-) Terminals at location #s 1, 2, 3 & 4 for the CAN Bus circuit**. Using (4) EU2Z-14421-CA (Motorcraft part # WT-1013) Terminals, the C405 male connector of the 14405 frame harness must have 4 wires added at location #s 4, 5, 12 & 13 for the CAN Bus circuit**. The C405 16 pin inline connector is located at the rear of the LH frame rail. This wire should be present if vehicle is equipped with factory installed rear view camera. This wire provides 12V+ to the BLIS modules. Confirm the presence of WH-BN /CBBB3 wire at location # 8 of C408 male connector of the 14405 frame harness. The C408 12 pin inline connector is located at the rear of the LH frame rail. This fuse should be present if vehicle is equipped with factory installed rear view camera. This fuse provides 12V+ to the BLIS modules.
(8) 84-2150 Grote (or equivalent) 18-22 gauge (Red) butt splices w/heat shrinkĬonfirm the presence of 7.5 amp fuse at location # F113 in the Power Distribution Box (Battery Junction Box – BJB). (20’) 83-8010 Grote (or equivalent) 3/8” polyethylene split wire loom (20’) 9744 Belden (or equivalent) 4-Conductor (2 twisted pairs x 22 gauge) Wire Pkg.) – required for vehicles with 8 pin mirror connecters (1) F元Z-14631-A LH Door Harness (Lariat wo/Tech. (1) F元Z-14630-E RH Door Harness (Lariat wo/Tech. (1) F元Z-17683-AF Mirror LH (Trailer Tow w/black textured skull cap) or equivalent mirror with BLIS capability (1) F元Z-17682-AF Mirror RH (Trailer Tow w/black textured skull cap) or equivalent mirror with BLIS capability (4) W505564-S450 Screw – BLIS Module to BLIS Module Mounting Bracket (8) W715133-S900 Screw – BLIS Module Mounting Bracket to Tail Lamp Housing (1) F元Z-14D189-B Bracket – LH BLIS Module Mounting (Required w/2015 – 2017 LED Tail Lamps) (1) J元Z-14D189-B Bracket – LH BLIS Module Mounting (Required w/2018 LED Tail Lamps) (1) F元Z-14D189-A Bracket – RH BLIS Module Mounting (Required w/2015 – 2017 LED Tail Lamps) (1) J元Z-14D189-A Bracket – RH BLIS Module Mounting (Required w/2018 LED Tail Lamps) Requires using FORScan to Disable Rear Lamp Outage: change BCM address 726-27-02 from xxxx xxxx x1xx (1 = Rear Lamp Outage Enabled) to xxxx xxxx x0xx (0 = Rear Lamp Outage Disabled). J元Z-13A409-G harness supports: BLIS, LED Tail/Reverse/Turn & Stop Lamps, LED Bed Lamps, Trailer Assist Lamp, Rear View Camera and Tail Gate Lock Actuator. Installing LED tail lamps is most easily accomplished by replacing the 13A409 tail lamp harness with the J元Z-13A409-G harness. Note: this BLIS installation guide assumes the vehicle has the XLT 302A level trim and already has fully functioning Non-King Ranch LED tail lamps (2015-17 H元Z-13404-D RH/H元Z-13405-DLH or 2018 J元Z-13404-F RH/J元Z-13405-F LH). This step will assist in identifying any DTCs that were/were not created as a result of the following procedure. Note: Prior to beginning, using FORScan or equivalent, check for any DTCs that may be present in any modules.
